Pull L=1.5” W=1”
Installs with short nail @ the bottom of plates to secure.
Plate L=4.5” (2 short nail install on each end of plate).
Single screw install with short nail on each end to secure..
Knob Diameter=1 1/4” Plate L=7.5”
Screw to screw=3/4” (2 screw install on knob)*Knob Full L=2” W=1.5”)Plate L=9” (plate secured w/2 short nails on ends)
Peg to center screw in=2.5” (see last pic).Knob L=1.5” Plate L=5 1/4”
Peg to screw=2.5” (peg to screw install/see last pic) Knob=1 1/4” Plate L=6”
Plate L=9.5” (Secure the install with short nails @ each end of plates)..
Plate L=6” (Secure the install with short pegs @ each end of plate closest to knob install/see last pic).
Screw to peg=1.5” (screw to peg install) Plate L=5.5”
Plate L=7”
3 hole install (see last pic) (Peg to Peg=2 3/4” with the center of that being knob for plate..
